Alien RFID Technology

Alien Tags – High-Performance, General Purpose RFID for a Variety of Applications
The Squiggle® family of tags is one of the industry’s most respected and performs in a broad-range of applications. Applications include retail/apparel, item-level tagging, transportation, pharmaceutical/life sciences, special form-factors and tags for mounting on challenging surfaces or in challenging environments.

Higgs® 4 Chip Highlights

Highly Integrated and Cost Effective
Cost Optimized
EPCglobal UHF Gen2 and ISO/IEC 18000-6c
512-Bits of Memory
- 128 EPC Bits, 128 User Bits, 64 Bit Unique TID, 32 Bit Access and 32 bit kill passwords
Low power operation for both read and programming
Exceptional operating range, up to 11m
Advanced security and anti-cloning technology
Pre-encoded with unalterable enterprise-wide serialization scheme

Higgs® 3 Chip Highlights

Highly Integrated and Cost Effective
Large User Memory
EPCglobal UHF Gen2 and ISO/IEC 18000-6c
800 Bits of Memory
- 96-EPC Bits extensible to 480 Bits, 512 User Bits, 64 Bit Unique TID (unalterable serial number), 32 Bit Access and 32 bit kill passwords
User Memory can be Block Perma-Locked as well as read password protected in 64 Bit Blocks
Low power operation for both read and programming
Exceptional operating range, up to 10m
